METAL DETECTOR HL-IMD-IIS-4018 FOR PRODUCTS ON A CONVEYOR BELT

Product description

The HL-IMD-IIS-4018 metal detector is a professional inspection device designed for detecting metal contamination in products transported on a conveyor belt. The machine is suitable for production plants, packaging facilities, the food industry, cosmetic industry, pharmaceutical industry, chemical industry and all production processes where product quality control and safety inspection are required.

The device detects ferrous metals, non-ferrous metals and SUS304 stainless steel. The metal detector operates as an automatic product inspection system on a conveyor. When metal contamination is detected, an audible alarm is activated and the conveyor belt stops, allowing the operator to remove the rejected product from the line.

The HL-IMD-IIS-4018 is equipped with an effective detection window of 400 mm width and 180 mm height. This makes it suitable for inspecting individual products, packages, cartons, sachets, bags, containers and other products that fit within the working detection range of the machine.

The 1800 mm long conveyor and 360 mm wide PU belt ensure stable product transport through the detection area. The machine body is made of SUS304 stainless steel, which makes cleaning easier and allows the device to be used in demanding production environments. The IP54 protection level provides protection against dust and splashing water, suitable for typical production line conditions.

Application

The HL-IMD-IIS-4018 metal detector can be used for the inspection of packed and unpacked products, individual packages, food products, loose products in packages, chemical products, cosmetic products, pharmaceutical products, sachets, cartons, bags, boxes, products on a conveyor belt and items requiring metal contamination control.

The machine is especially suitable for processes where metal contamination must be detected before further packing, storage or shipment to the customer.

Main advantages

Professional metal detector for production line operation

Detection of ferrous metals, non-ferrous metals and SUS304 stainless steel

Effective detection window 400 × 180 mm

1800 mm conveyor length

360 mm wide PU belt

Audible alarm after metal detection

Automatic belt stop after metal contamination detection

Product memory for 52 product types

Stable operation and simple handling

SUS304 stainless steel construction

IP54 protection level

Suitable for different products and packages

Suitable for quality control and production safety inspection

Possibility of using an additional flipping / rejecting device

Reject bin without lock included according to configuration

Technical data

Model: HL-IMD-IIS-4018

Machine name: metal detector / metal detection machine

Detection sensitivity without product: Fe ≥ 1.0 mm, Non-Fe ≥ 1.5 mm, SUS304 ≥ 2.0 mm

Effective detection window width: 400 mm

Effective detection window height: 180 mm

Conveyor length: 1800 mm

Belt width: 360 mm

Belt type: PU belt

Belt speed: 25 m/min

Product memory: 52 types

Rejecting system / reaction after metal detection: audible alarm, belt stop

Height from floor to belt: 750 + 100 mm

Features: single frequency, dual channel

Body material: SUS304 stainless steel

IP level: IP54

Power supply: AC 220 V, single phase, 60 Hz

Gross weight: approx. 340 kg

Equipment

HL-IMD-IIS-4018 metal detector

Conveyor belt with PU belt

Control panel

Audible alarm

Belt stop system after metal detection

Flipping / rejecting device

Reject bin without lock

Technical notes

The stated detection sensitivity parameters refer to testing performed with test samples placed on the belt without product.

Actual detection sensitivity may vary depending on the type of inspected product, product composition, moisture level, temperature, package size, working conditions and machine settings.

Before starting production, it is recommended to carry out tests using the customer’s actual product and to adjust the metal detector settings accordingly.

Additional information

The machine is supplied with CE.

Control panel in Polish or another required language.

Instruction manual in Polish or another required language.

We provide service and access to spare parts.
